250 Old Murdock Rd Troutman, NC 28166-9655

DISTRICT OI NC CB LC HB LI & HI Office and Institutional Neighborhood Center Central Business Local Commercial Highway Business Industrial 1. DEVELOPMENT HI is Conditional Only A. Maximum Density 4 dwelling units/acre no max no max No max no max n/a B. Required Open Space/ Park Space n/a 10% n/a n/a n/a n/a C. Perimeter Buffer (see also 5.1.5.A) Buffers required on all sides None unless adjacent to existing RP, RS or RT None unless adjacent to existing RP, RS or RT None unless adjacent to existing RP, RS or RT Buffers required at side and rear of lot Buffers required at side and rear of lot 2. LOT CONFIGURATION A. Lot Size .25 acre n/a n/a n/a n/a n/a B. Maximum Lot Coverage (Note 1) 80% 80% 100% 80% 80% 80% C. Frontage Buildout n/a 50% min. 75% min. n/a n/a n/a 3. PRIMARY BUILDING PLACEMENT A. Front Setback 15 feet 0 feet min 0 feet min 20 feet 10 feet 30 feet 15 feet max 5 feet max B. Side Setback - Corner (Note 2) 15 feet 0 ft min 0 ft min 20 feet 10 feet 30 feet 10 ft max 15 ft max C. Side Setback - Interior (Note 2) 15 feet 0 feet or 10 ft min between detached buildings 5 ft max 10 feet 0 feet or 10 ft min between detached buildings (25 adjacent to residential district) 10 ft, (100 ft adjacent to residential district) D. Rear Setback 25 feet 5 ft min 5 ft min 20 feet 20 ft 25 ft, (100 ft adjacent to residential district) E. Rear Setback from Alley n/a 0 ft 0 ft n/a n/a n/a Garage doors shall be a minimum of 15 feet from alley centerline. Setbacks may be increased to accommodate parking outside of the garage. F. Attached Garage Setback (from front facade) n/a attached garages along frontage are prohibited attached garages along frontage are prohibited n/a n/a n/a In addition to the setback requirements listed above, garage doors which face a public right-of-way, except for rear alleys, must be set back a minimum of 20 ft from the sidewalk or 30 ft behind the right-of-way if no sidewalk is present. 4. ACCESSORY BUILDING PLACEMENT (SEE ALSO 3.4.2 & 3.4.3) A. Side Setback - Corner 20 feet 3 ft min 2 ft min 20 ft 3 ft min 20 feet B. Side Setback - Interior 10 feet 5 ft min 0 ft min 10 ft 10 ft min 5 ft (30 adjacent to residential district) C. Rear Setback 10 feet 5 ft min 3 ft min 10 ft 10 ft (20 adjacent to residential district) 10 ft (30 adjacent to residential district) D. Rear Setback from Alley n/a 3 ft min 3 ft min n/a n/a Garage doors shall be a minimum of 15 feet from alley centerline. Setbacks may be increased to accommodate parking outside of the garage. E.
